Meshnology N39 WiFi LoRa 32 V4 Meshtastic Device Kit
Overview
The Meshnology N39 is an upgraded ESP32-S3 LoRa development board based on the Heltec WiFi LoRa 32 V4 platform. It integrates Wi-Fi, Bluetooth BLE, and LoRa communication in a single device, making it ideal for Meshtastic networks and IoT applications.
The N39 series is currently out of stock. All new orders will be processed as pre-orders, with shipments expected between early April and April 20 📦
Core Highlights
- ESP32-S3 + SX1262 Chipset – Supports Wi-Fi, Bluetooth BLE, and LoRa communication in one platform.
- High Memory Upgrade – 2MB PSRAM + 16MB Flash for improved performance and UI rendering.
- High-Power LoRa Transmission – Up to 27±1 dBm for extended communication range.
- Integrated Design – Built-in casing, OLED display protection, and improved antenna stability.
- Solar Power Support – SH1.25-2P solar input (4.4–6V / ≤540mA).
- Advanced Power Management – Smart charging, protection circuits, and auto power switching.
- GNSS Expansion Ready – SH1.25-8Pin interface for GPS module expansion.
- Ultra-Low Power Mode – <20μA standby with independent GNSS power control.
Features & Video Showcase
- MCU: ESP32-S3R2 dual-core processor
- LoRa Chip: SX1262 (high-power transmission)
- Memory: 2MB PSRAM + 16MB Flash
- Wireless: Wi-Fi 802.11 b/g/n + Bluetooth BLE + LoRa
- Power Interface: USB Type-C with protection circuit
- Battery Support: Smart charging/discharging system
- Solar Input: 4.4–6V / ≤540mA
- GNSS: External expansion supported (SH1.25-8Pin)
How It Works
- LoRa Communication: Between two N39 devices
- Bluetooth Connection: Between device and mobile Meshtastic app
- USB / WiFi / Bluetooth: For PC configuration and firmware management
Applications
- Smart city IoT networks
- Industrial automation systems
- Smart agriculture monitoring
- Wireless sensor networks
- Security & tracking systems
- Meshtastic off-grid communication projects
A powerful open-source LoRa development platform designed for engineers, makers, and IoT developers building next-generation wireless systems.
Package Includes
- 1 × ESP32-S3 LoRa V4 Development Board
- 1 × 3000mAh Rechargeable Li-ion Battery (Pre-installed)
- 1 × Protective N39 Case
- 1 × 863–928MHz Antenna
Docs & Resources
Related Products
| Color |
Green, Black, Twilight Purple, Green+Black, Green+Twilight Purple, Black+Twilight Purple, Green+Black+Twilight Purple |
|---|---|
| Size |
Only Case, 1 Set (Board+Battery+Case), 2 Sets (Board+Battery+Case) |
