Meshnology N40 ESP32 Development Board
Overview
The N40 ESP32 Expansion Board is a professional-grade development and prototyping platform designed to simplify ESP32 and ESP32-S3 hardware integration. It provides full GPIO breakout access, stable power management, and industrial-friendly wiring options, making it ideal for rapid prototyping, testing, and deployment.
Whether used for IoT development, embedded system debugging, or production-level wiring, the N40 significantly improves accessibility and reliability of ESP32-based projects.
Core Features
- Wide Power Input Support – DC 5.5×2.1 interface, supports 7–12V input (recommended 12V/2A stable power supply).
- Full IO Breakout Design – 2.54mm headers expose all ESP32 / ESP32-S3 GPIO, power, and reset pins.
- Industrial Screw Terminals – KF terminal blocks for secure and vibration-resistant wiring connections.
- Integrated Level Shifting – Built-in TI TXS0108EPWR high-speed level shifter (up to 60 Mbps).
- Real-Time IO Indicators – Onboard LED indicators for instant GPIO status monitoring.
- Developer-Friendly Layout – Clean pin mapping optimized for debugging and expansion.
Specifications
- Board Dimensions: 87.0 × 80.0 × 12.0 mm
- Mounting Hole Spacing: 80.2 × 73.2 mm (3 mm standard screws)
- Operating Temperature: -20°C ~ 70°C
- Power Input: DC 5.5×2.1, 7–12V / 2A
- IO Interface: 2.54mm pitch headers for GPIO / power / reset
- Terminal Blocks: 2.54mm KF screw terminals for direct wiring
- Level Shifter: TI TXS0108EPWR (high-speed bidirectional)
- Indicators: Per-channel IO status LEDs
IO Expansion Layout
- J1 / J3 / J9: Left-side GPIO, power, and enable signal breakout
- J2 / J4 / J10: Right-side GPIO, communication, and system control pins
Applications
- ESP32 / ESP32-S3 rapid prototyping
- IoT device development and debugging
- Industrial control system wiring
- Sensor integration and expansion testing
- Embedded system education and development
Package Includes
- 1 × N40 ESP32 Breakout Board
- 1 × 12V / 2A Power Adapter
- Optional: ESP32 WROOM Core Board
- Optional: ESP32-S3 WROOM Core Board
- Optional: YD-ESP32-S3 N16R8 Core Board
Note
Core board options are optional and may vary depending on configuration. Please confirm compatibility before purchase.
